• Compact and lightweight
• Beam divergence ≦0.5 mrad
• Low power consumption
• Measurement rates up to 10 Hz
• Laser 1.54 µm wavelength
• Eye safe Class 1M
• Easy for OEM systems/devices intigration
Applications：
• Counter drone & UAV activities • Observation and surveillance
• Aerial collision prevention • Border and port control
• Off shore rescue • Naval systems
• Drone & UAV gimbals • Vehicle mounted systems
RANGE PERFORMANCE | |
Maximum range | 8,000m |
Range Performance on 2.3X2.3m target size reflectivity: 30%, observer visibility ≥10km | ≥6,000m |
Range Performance on 1.75 X 0.75m target size reflectivity: 30%, observer visibility ≥10km | ≥2,500m |
Minimum range | 50m |
Range accuracy | ≤±2m (RMS) |
Multiple target detection | Up to 3 targets |
Target Discrimination | 50m |
False alarm rate | ≤ 1% |
OPTICAL | |
Wavelength | 1535nm |
Repetition rates | Max. 10Hz |
Divergence | ≤0.3mrad |
Eye safety | Class 1 |
ELECTRICAL | |
Hardware interface | 8pin Molex |
Communication interface | RS422, 115200bps |
Power supply | 9 VDC to 16VDC |
Power consumption | Average ≤ 1.5W, Peak ≤ 5W |
ENVIRONMENTAL | |
Operating temperature range | -40°C to + 65°C |
Storage temperature range | -55°C to + 70°C |
PHYSICAL | |
Weight | ≤120g |
Dimensions (L/W/H) | 71mm x 60mm x 46mm |
Note: The target color, sizes, surface shape, atmospheric visibility etc. may have an impact
on the measurement range. The specific technical parameters are subject to the product manual
and are subject to change without notice.
