Nd: YAG

● High gain
● Low threshold
● High efficiency
● Low loss at 1.06μm
● Good thermal conductivity
● High anti-thermal shocking

EMAIL

Nd: YAG is widely used in industrial, medical, military and scientific research fields. Nd: YAG continues being as the best of the rare earth garnet materials that are characterized by four-level laser operation which permits low threshold pulse and CW operation.

Chemical Formula,Crystal:Activator

Y3Al5O12 :Nd3+

Activator Concentration

Nd3+: 0.21.1at%

Growth direction of crystal

[111] or [100]

Wavefront Distortion

λ/8 per inch @632.8nm

Extinction Ratio

≥30dB

Dimensions

Diameter: 1~50mm ,Length: 0.3~220mm

Tolerances

Diameter: ±0.02mm, Length: ±0.2mm

Barrel Surface

Fine ground, Polished or Grooved

Parallelism

≤10″

Perpendicularity

≤5'

Surface Flatness

λ/10 per inch @632.8nm

Surface Quality

10-5(MIL-PRF-13830B)

Chamfer

0.1mm@45°

Clear Aperture

>95%

Anti-Reflection Coating

R<0.15%@1064nm

Damage Threshold

>750MW/cm2

Note: Parameters above can be customized as required.

The active element,OPO crystal and Q-switch crystal and Narrow band filters@1064nm,T>90% can be suplied together as required for specified solutions.
